    Customized Flexible Pipe Coil Stretch Wrapping Machine Vertical Type Bearing 100KG Coil

    Ask Lasest Price
    Brand Name : jlpack
    Model Number : GD300-N
    Certification : ISO9001,CE
    Payment Terms : T/T
    Delivery Time : Stand-alone 1 week ,the packing line 150days
    Supply Ability : 200 sets/Year
    • Product Details
    • Company Profile

    Customized Flexible Pipe Coil Stretch Wrapping Machine Vertical Type Bearing 100KG Coil

    Customized Flexible Pipe Coil Stretch Wrapping Machine Vertical Type bearing 100KG coil

    Vertical type packing machine​ application:

    The vertical type customized flexible pipe coil stretch packing machine is applied for packing cable coils in various size in an automatic and more efficient way, the machine is also widely used for pipe coils, steel coils, copper strips, aluminum strips, and other products, to make the product well-protected&sealed, and convenient for transportation.


    Vertical type packing machine​ main parameters:

    ModelGD300-N
    Coil OD300mm-1000mm
    Coil ID200-600mm
    Coil width50-300mm
    Coil weight10-100KG
    Ring speed30r/min-80r/min,adjustable
    Packing speed25-45s/pcs
    Overlap rate10%-90%
    Packing materialPlastic woven tape/Stretch film
    Material sizeID:76mm; OD:80-150mm;width:90mm
    Power voltage380V, 50HZ
    HMI operationOptional
    Synchronous wrappingOptional

    Note: the datas are only for reference, the machine can be custom designed according to specific object size.


    Vertical type packing machine basic features:

    1. The pipe coil wrapping machine is with top-opening structure which is convenient for loading and offloading by crane.
    2. Steady tension control system.
    3. Soft start, soft stop and precise reset of the ring.
    4. Durable high anti-friction PU adopted for friction wheels.
    5. The wrapping ring height is adjustable, to suit for cable coils with different ID and OD.
    6. Indicator lamp alarms automatically when trouble occurs.
    7. PLC control system.
    8. The overlapping rate and tension of the packing tape can be adjusted according needs.
    9. Integral casting structure of the turning ring,running smoothly and strongly.
    10. Independent control cabinet, easy for operation and maintenance.
    11. Safe guardrails and covers, ensure safe operation.
    12. The rollers are wrapped by polyurethane, which can protect the product effectively.
    13. HMI is available for option for automatic operation.

    Customized Flexible Pipe Coil Stretch Wrapping Machine Vertical Type Bearing 100KG Coil
